Description
Specification
System
Operation
– Keypad: Single Mechanical Button
– Reader: MIFARE Card
– Detection Distance: 1 m (39.37 in.)
Vertical: 125°
Day/Night
: ICR
Interface
Audio Input: Omnidirectional Microphone | Output: Built-in Speaker | Two-way Talk
Audio Compression:G.711
Door Control: Two (2) Channels: | One (1) Relay Out for Main Lock | One (1) Channel Extended by Access Control Module
Alarm Input: Two (2) Channels: | One (1) Channel, Unlock Button | One (1) Channel, Feedback
– Main Processor: Embedded Micro Processor
– Operating System: Embedded Linux
– RS485: One (1) Port
– Tamper Switch: One (1)
– Memory: Micro SD, 64 GB maximum
– WiFi: IEEE 802.11b/g/n
– Ethernet: 10/100 Mbps, Self-adaptive
– Network Protocol: TCP/IP
– Safety: EN 60950: 2006+A2:2013
– Power: 12 VDC, PoE (802.3 af)
– Power Consumption: Standby: ≤ 1 W | Operation: ≤ 7 W
Operating Temperature: -30° C to +60° C (-22° F to +140° F)
Operating Humidity: 10% to 90%, Relative
Ingress Protection: IP65
Material: Plastic
Dimensions: 135.0 mm x 70.40 mm x 34.40 mm | (5.31 in. x 2.77 in. x 1.35 in.)
Net Weight: 0.40 kg (0.88 lb)
Installation: Surface- or Flush-mount
