Description
The hAP mini is a small 2GHz wireless access point for home or small offices. It has three ports, which are configured as one Internet port and two LAN ports, but can be reconfigured as desired, using the powerful RouterOS configuration options.
The powerful 650MHz CPU gives you full access to the wide variety of features provided by the versatile RouterOS operating system, but if all you want is a simple access point – it is already configured out of the box. You simply need to open it’s web configuration page and provide a password for it.
Powering
PoE in: Passive PoE
PoE in input Voltage: 10-30 V
Number of DC inputs: 1 (PoE-IN)
Max power consumption: 6 W
Wireless
Antenna gain dBi for 5 GHz: 9
Wireless 5 GHz standards: 802.11a/n
Wi-Fi generation: 4
Wireless 5 GHz Max data rate: 300 Mbit/s
Wireless 5 GHz number of chains: 2
Wireless 5 GHz chip model: AR9344
Ethernet
10/100 Ethernet ports: 1
Wireless specifications
5 GHz
6MBit/s
54MBit/s
MCS0
MCS7
Transmit (dBm)
25
20
25
19
Receive Sensitivity
-96
-80
-96
-75
