Description
President Teddy ASC CB Radios/Ham Radios AM/FM Transceivers
General Specification
Technical Specification
Supply
AM
FM
Channel selector
VFO mode
Volume
RF Power
Squelch
ASC
Display
Frequencies display
S-meter
Public address
Talkback
Filter ANL
Filter NB
Filter HI-CUT
RF Gain
Mike-Gain
Scan
F/Menu function key
Key Beep
Roger beep
Dual watch
SWR (Power Reading /SWR)
Preset channel
Microphone plug
External loudspeaker jack
Size
Weight
: 13.2 V
:
:
: rotary
:
: Volume adjustment and ON/OFF
:
: Manual squelch
:
: LCD multifunction
:
: Digital
:
:
:
:
:
:
:
:
:
:
:
:
:
: EMG 1/2
: front (6 pins)
:
: 125 (W) x 175 (D) x 45 (H) mm
: 0,9 kg
Modulation modes
Frequency ranges
Antenna impedance
Power supply
Size
Weight
Accessories supplied
Transmission
Frequency allowance
Carrier power
Transmission interference
Audio response
Emitted power in the adj. channel
Microphone sensitivity
Drain
Modulated signal distortion
Reception
Maxi. sensitivity at 20 dB sinad
Frequency response
Adjacent channel selectivity
Maximum audio power
Frequency image rejection rate
Intermediate frequency rej. rate
Drain
Squelch sensitivity
: AM / FM
: from 28.000 MHz to 29.700 MHz
: 50 ohms
: 12 V
: 125 (W) x 175 (D) x 45 (H) mm
: 0,9 kg
: power cord with fuse, 1 microphone with hanger, mounting bracket, screws
: +/- 300 Hz
: 13 W AM (50 W PEP) / 35 W FM
: inferior to – 50 dBm
: 300 Hz to 3 KHz in AM/FM
: inferior to 20 µW
: 3,0 mV
: 7 A max. (with modulation)
: 2 %
: 0,7 μV-110 dBm/0,35 μV-116 dBm
: 300 Hz to 3 kHz in AM/FM
: 60 dB
: 3 W
: 60 dB
: 70 dB
: 500 mA max
: minimum : 0.2 μV – 120 dBm / maximum : 1 mV – 47 dBm
