TOA Pendant Speaker PE-64

The PE-64 is a pendant speaker designed for ceiling suspension installations. Considered in architectural design, it can blend in with lighting equipment.

Features

Stylish and outstanding design inspired by the finest lighting fixtures
Sturdy cable extendable up to 5 meters
Repaintable
Input impedance easily changeable
Ideally suited for BGM and announcements

Description

The PE-64 is a pendant speaker designed for ceiling suspension installations. Considered in architectural design, it can blend in with lighting equipment. A directly-attached 5 m (16.4 ft) cable allows the speaker to be suspended from the high celling. The PE-64 is driven on high-impedance (100 V and 70 V) line. The input power (impedance) can be easily changed at the upper side of the speaker. The speaker is easy to repaint so as to meet a wide range of design needs.

Enclosure: Bass-reflex type
Rated Input: 6W (100V line), 3W (70V line)
Rated Impedance: 100V line: 1.7kΩ (6W), 3.3kΩ (3W), 10 kΩ(1W)
70V line: 1.7kΩ (3W), 3.3kΩ (1.5W), 10 kΩ (0.5W)
Sensitivity (1W, 1m): 90dB (500 – 5,000Hz, pink noise)
Frequency Response: 100 – 18,000Hz (peak –20dB)
Speaker Component: 5″ (12cm) cone-type
Speaker Cord: 2-core cabtyre cord 5m (16.4 ft)
Applicable Cable: 600V vinyl-insulated cable (IV wire or HIV wire)
Solid copper wire: ø0.8 – ø1.6mm (equivalent to AWG 20 – 14)
7-core twisted copper wire: 0.75 – 1.25mm2 (equivalent to AWG 18 – 16)
Connetion: Push-in connector (bridging terminal-2 branch type)
Finish: Enclosure: HIPS resin, off-white (RAL 9010 or equivalent colour)
Grille: Surface-treated steel plate net, off-white (RAL 9010 or equivalent colour), paint
Dimensions: ø186 × 251(H) mm (ø7.32″ × 9.88″) (unit only)
Weight: 1.5kg (3.31 lb) (unit only)
Accessory: Ceiling bracket × 1, Mounting hanger × 1, Ceiling cover × 1, Speaker mounting screw (4 × 16) × 4
