Zcom VN-DB04 Smart Camera Video Doorbell

  • Wireless Battery Powered Smart Camera(Outdoor IP65)
  • IR LED: 6 pcs, IR Range: 10M
  • Lens: 2.8mm Board lens
  • Motion detection by PIR Sensor, Support SD Card up to 32GB, WDR
  • Wifi auto match, mobile app (Tosee) support iPhone and Android
  • Push alarm to smart phone, two way audio
  • Size: Size: 95(L)mm x 55(W)mm x 85mm(H)
  • Weight: 0.6 Kg



Categories: ,

Description

  • Solution: 3518EV200 + F23
  • Resolution: 1080P (1920×1080px)
  • Field of View: 166°
  • Night Vision: 6 IR LEDs,10m (16ft) Night Vision Lens 2.8mm Board lens
  • Video Quality: HD 1080P @ 25FPS
  • Scene Option: BLC, IR, HLC, Motion Compensation, WDR
  • Motion Sensor: Smart PIR Sensor (Sensitivity Editable)
  • D/N Mode: Auto switch by Light Sensor
  • Pickup Device: Internal Microphone
  • Audio Output: Speaker
  • Type: 2-way Audio with Noice Cancellation
  • Network: 2.4GHz WiFi (IEEE 802.11 b/g/n)
  • OS Require: iOS (v7.0 or newer) or Android (v4.0 or newer)
  • Memory Device: 8GB Class10 High-speed TF-card Preinstalled
  • Storage Capacity: Max Support 32GB TF-card
  • Red LED Blink: Power OK, Waiting for WiFi Connection
  • Blue & Red Blink: WiFi Setting Succeed, Waitting for APP Connection
  • Blue LED Blink: Power & Network OK, Device in Working Status
  • LED OFF: No Power / StandBy Mode
  • Power Type: Rechageable 18650 Battery or Hardwire AC8V-24V
  • Consumption: Working mode: 170mA Standby Mode: 200μA
  • Dimensions: 95(L)mm x 55(W)mm x 85mm(H)
  • Packing size: 150(L)mm x 140(W)mm x 95mm(H)
  • Weight: 600g
  • Working temperature: -20℃ to 55℃
  • Relative humidity: 85% non-condensing
